SBW 50KVA 3/3
SBW 50KVA 3/3
Overview
- Easy operation
- Reliable operation
- Lack phase protections
- Overcurrent protections
- Overvoltage protections
- Stable voltage regulation
- Convenient maintenance
- Undervoltage protections
- High power and efficiency
- Without waveform distortion
- Additional distortion less than 1%
- High adaptability to all kinds of load
- Stable and undistorted output waveform
- Stable operation in complicated conditions
- Single unit power capacity upto above 2000KVA
- Load regulation and grid regulation less than 2%
- Equipped with automatic and manual power transmission
Specifications
| Input | : |
| Nominal Voltage | Phase voltage 220VAC±20%, Line voltage 380VAC±20% |
| Frequency | 50/60Hz |
| Phase | Three phase five wire (3ø + N + PE) |
| Output | : |
| Rating Voltage | Phase voltage 220VAC, Line voltage 380VAC |
| Voltage Regulation | 30KVA~100KVA: ≤±3%, |
| Accuracy | 150KVA~800KVA: ≤±2%~5% |
| Waveform Distortion | Distortionless |
| Efficiency | ≥95% |
| Noise | ≤50dB |
| Distortion | No additional waveform distortion |
| Response Time | ≤1.5 sec (Ambient Voltage Varies 10%) |
| Overload Capacity | 120% of rated current: >10 secs |
| Display Mode | LED indicators, Analog voltage meter |
| Input/Output | Terminal block |
| Protections Function | Overvoltage, Lack-phase, Phase order protection & Mechanical failure protection |
| Insulation Resistance | ≥2MΩ |
| Dielectric Intensity | Low frequency sinewave voltage 1500V for 1 min, no breakdown and flashover phenomenon |
| Physical | : |
| Dimensions (WxDxH) (mm) | 800 x 560 x 1320 |
| Packaging (WxDxH) (mm) | 865 x 625 x 1475 |
| Net Weight (kg) | 260 |
| Gross Weight (kg) | 280 |
| Model/Capacity | : |
| Model | SBW |
| Rating Capacity | 50KVA |
| Environment | : |
| Temperature | -10°C~+ 40°C |
| Humidity | 0%~95%RH (Non-condensing) |
| Altitude | <1000 m |
| Working Mode | Continuous working |
