MH-600
MH-600
Overview
- Cold start
- Super powerful charger built-in
- Overload protection
- Fully digitized microprocessor control LED
- Short circuit protection
- Energy saving function with UPS green mode
- Wide input voltage range
- Intelligent longer backup series
Specifications
Input | : |
Nominal Voltage | 220VAC |
Voltage Range | MH 600~MH 1500, Inverter mode: 90V~270V, UPS mode: 135V~270V, MH 2000~MH 5000 , Inverter mode: 90V~270V, 2KVA/3KVA: 160V~265V for 4KVA/5KVA, UPS mode: 135V-270V, 2KVA/3KVA: 190V-260V for 4KVA / 5KVA |
Phase | Single phase & Ground |
Frequency | 38-70Hz |
Generator Input | Support |
Output | : |
Voltage Range | MH 600~MH 1500 Inverter mode: 90V-270V UPS mode: 190V-260V Battery mode: 220v±10% MH 2000~MH 5000 Inverter mode: 90V-270V UPS mode: 190V-260V Battery mode: 220V±10% |
Frequency | MH 600~MH 1500
Utility mode: Same as utility, Battery mode: 50Hz±1Hz MH 2000~MH 5000 Utility mode: Same as utility Battery mode: 50Hz±1Hz |
Waveform | MH 600~MH1500 Utility mode: Tracking utility Battery mode: Sinewave MH 2000~MH 5000 Utility mode: Tracking utility Battery mode: Sinewave |
Power Factor | 0.8 |
Transfer Time | 6ms |
Model/Capacity | MH 600: 600VA/480W |
Battery | : |
Voltage | MH 600/MH 800: 12VDC |
Recharge Voltage | MH 600/MH 800: 13.8±0.3V |
Recharge Current | MH 600 |
AC Mode | 1. Load<100%, Working normally
2. Load<100%~120%, shut down after 3 mins and then restart automatically after 30 secs 3. Load<120%~130%, overload, shut down after 30 secs and then restart automatically after 30 secs 4. Load<130%, overload, will shut down immediately and then restart automatically after 30 secs *After repetitive 3 times, if overload remains, transfer to fault mode, needs restart manually |
Battery Mode | 1. Load<100%,Working normally
2. Load<100%~110%, Overload, shut down after 10 secs and then restart automatically after 30 secs 3. Load<110%, overload, will shut down immediately and then restart automatically after 30 secs *After repeat 3 times, if over-load remains, transfer to fault mode, needs restart manually |
Physical | : |
Model | MH 600 |
Dimensions (WxDxH) (mm) | 260 x 252 x 163 |
Packaging (WxDxH) (mm) | 380 x 375 x 225 |
Weight (kgs) | MH 600: 10.7 |
